PalaceToolkit¶

A lightweight Python package that integrates Palace and Gmsh into a unified simulation workflow.

What is PalaceToolkit?¶

PalaceToolkit bridges the gap between mesh generation and full-wave electromagnetic solving. In a single Python script you can:

Define geometry with the Entity abstraction and Gmsh's OpenCASCADE kernel.
Generate meshes via an automatic boolean pipeline that handles material priorities, interface labelling, and physical-group assignment.
Configure & run Palace — build JSON configs from entity definitions and launch solves through the Apptainer container.
Post-process results — extract S-parameters, impedance, effective index, and render interactive 3D mesh viewers.


Getting Started	Installation, meshing, simulation setup, post-processing
Examples	Waveguides, antennas, and planar microwave circuits
Full Course	Structured video lectures
Palace docs	Upstream Palace reference
Gmsh docs	Upstream Gmsh reference
